Fiber Optic Outdoor ODC MPO Connector

Get ready to experience the power of our revolutionary ODC-MPO Connector, a cutting-edge solution designed to withstand even the harshest environments.

This multi-fiber connector integrates a standard MTP ferrule interface with a metal housing for ultimate protection and longevity.

Engineered for use in telecommunications, smart grids, industrial fields, and LAN, the ODC-MPO Connector is your reliable interface for active components.

This UV-protected connector can be used both indoors and outdoors, offering a seamless blend of functionality and versatility.

Key Features

• Cable Assembly Compatibility: Our ODC-MPO Connector supports a wide range of fiber quantities, from 4 to 24, offering flexibility for various network requirements.
• Convenient Installation: The ODC-MPO Connector is designed for ease-of-use. Its unique structure enables quick, one-handed installation.
• Fiber Options: The connector accommodates various fiber types including multi-mode OM1, OM2, OM3, OM4, single-mode 9/125um G652D, and 9/125um G657A fibers for diverse application requirements.
• Compliance: Our product is IP67 and RoHS compliant, ensuring it meets the highest standards for safety and environmental protection.
• Performance Testing: We guarantee the quality of our ODC-MPO Connector with 100% performance testing for your peace of mind.

Technical Specifications

• Fiber Termination: The ODC-MPO Connector terminates 4, 6, 8, 12, or 24 fibers, offering versatility for your networking needs.
• Connectivity Systems: Available as ODC-MPO Male or Female for flexible integration.
• Operating Temperature: The connector is designed to withstand temperatures ranging from -40℃ to +80℃, ensuring stable performance in diverse conditions.
• Insertion Loss:
  • For Single Mode (SM): <(1.6+0.0003*L) dB@ 1310nm/1550nm.
  • For Multi Mode (MM): <(1.2+0.003*L) dB@ 850nm/1300nm.
    (Cable assembly IL according to IEC 61300 3-4 Method C, “L” is the product length in meters)

Experience the ODC-MPO Connector Advantage

With the ODC-MPO Connector, you're investing in a product that offers an ideal balance between robustness and performance.

Its unique design and advanced features make it a must-have for any tech-savvy individual or business looking to optimize their fiber optic network.

Experience the power of our ODC-MPO Connector today, and take your connectivity to the next level.

Features/Benefits

• Cable assembly is compatible with fiber quantities ranging from 4 to 24;
• Convenient installation;
• Multi-mode OM1, OM2, OM3, OM4 , single-mode 9/125um G652D and 9/125um G657A fiber options
•  available for different requirements;
• IP67 & Rohs compliant;
• 100% performance testing;
